series:3JG2

Engineered for ISO 13849 safety-rated vehicles, Grayhill’s 3JG2 CAN Bus Vehicle Interface Controllers (VICs) Plus offer advanced control functionality in a compact, low-profile design. Available in three mechanical configurations—a rotary encoder, joystick encoder, or proportional joystick—each with optional center pushbuttons, the 3JG2 delivers intuitive navigation and selection for modern vehicle systems.

Designed for rugged environments, our CAN Bus VIC Plus is sealed to IP67 and tested against shock, vibration, extreme temperatures, and ingress. Its modern flush styling includes no-tool, snap-in front mounting for streamlined installation and a clean look within cab interiors. Built-in diagnostics monitor supply voltage, confirm indicator operation, and detect button malfunctions, helping improve uptime and reliability in the field.

With support for J1939 and CANopen protocols, dimmable LED indicators, customizable keypad legends, and a low-current sleep mode, the 3JG2 VIC Plus is a flexible, configurable solution for OEMs requiring multifunctional input in demanding conditions.

– No-tool Snap-in Front Mounting
– Designed for ISO 13849 Safety Rated Vehicles
– Keypad buttons: 6
– Modern Flush Styling
– J1939, CANopen, and CANbus Safety Communication Protocols
– Low Current Sleep Mode
