Hall-Effect Encoder series:68A
- – High resolution
- – Quadrature output with push/pull circuitry
- – Low power consumption: available in 3.3Vdc or 5Vdc
- – Long operational life >1M cycles
Racks series:70XRCX8
8 Channel
Racks series:70XRCX4
4 Channel
Racks series:70XRCX24
24 Channel
Racks series:70XRCX16
16 Channel
IOMODULE series:IOMODULES
I/O Modules series:70X-ODCXR
Switch AC or DC with the Same Module
I/O Modules series:70X-ODC
DC Output
- Agency Approval: UL, CSA, CE, TUV
I/O Modules series:70X-OAC
AC Output
- Agency Approval: UL, CSA, CE, TUV
I/O Modules series:70X-IDCX
AC/DC Input
- Agency Approval: UL, CSA, CE, TUV
I/O Modules series:70X-IDC
DC Input
- Agency Approval: UL, CSA, CE
I/O Modules series:70X-IAC
AC Input
- Agency Approval: UL, CSA, CE, TUV
Metal Shaft series:94R
Sealed Base
- Life Rating: 10,000
- Actuation: Rotary
- Circuitry: Octal, BCD & Hexadecimal
Thru-Hole and Surface Mount series:94H
Thru-Hole & Surface Mount
- Life Rating: 10,000
- Actuation: Rotary
- Circuitry: Octal, BCD & Hexadecimal
Thru-Hole DIP Switches series:90B
Machine Insertable
- Life Rating: 2,000
- Actuation: Top Recessed Slide
- Circuitry: SPST
Thru-Hole DIP Switches series:79
- Life Rating: 2,000
- Actuation: Raised Slide
- Linear Circuit Selector or Coded Output
Thru-Hole DIP Switches series:78B
Right Angle Option
- Life Rating: 2,000
- Actuation: Raised Slide
- Circuitry: SPST
Thru-Hole DIP Switches series:78
Sealed Base
- Life Rating: 2,000
- Actuation: Raised or Recessed Slide
- Circuitry: SPST to 4PST
Thru-Hole DIP Switches series:76-78 DPDT
DPDT with common poles or DPDT with 4 isolated circuits
- Life Rating: 2,000
- Actuation: Raised or Recessed Rocker, and Toggle
- Circuitry: DPDT
Thru-Hole DIP Switches series:76-78
Sealed Base
- Life Rating: 2,000
- Actuation: Raised or Recessed Slide or Rocker, Top or Side Actuated Toggle
- Circuitry: SPDT
Thru-Hole DIP Switches series:76
Sealed Base
- Life Rating: 2,000
- Actuation: Raised or Recessed, Rocker & Piano
- Circuitry: SPST
Surface Mount DIP Switches series:97
Half-Pitch 0.050 [1,25mm] Centers
- Life Rating: 1,000
- Actuation: Top Recessed Slide
- Circuitry: SPST
Surface Mount DIP Switches series:90HB
Low Profile DIP
- Life Rating: 2,000
- Actuation: Top Recessed Slide
- Circuitry: SPST
Surface Mount DIP Switches series:90HB
Low Profile DIP
- Life Rating: 2,000
- Actuation: Top Recessed Slide
- Circuitry: SPST
Surface Mount DIP Switches series:78H
Standard DIP Packages
- Life Rating: 2,000
- Actuation: Side Toggle
- Circuitry: SPST, DPST
Surface Mount DIP Switches series:76HP
– Piano DIP
- Life Rating: 2,000
- Actuation: Side Toggle
- Circuitry: SPST
CAN Bus Vehicle Interface Controller Plus series:3JG2
– No-tool Snap-in Front Mounting – Designed for ISO 13849 Safety Rated...
- Keypad buttons: 6
- Modern Flush Styling
- J1939, CANopen, and CANbus Safety Communication Protocols
- Low Current Sleep Mode
CAN Bus Vehicle Interface Controller series:3JG1
Keypad buttons: 5
- Long life cycle: 1M for encoder and pushbutton, 500K for joystick
- J1939 and CANopen versions
- Dimmable LED indicators and legends
- Sealed to IP67
CAN Bus Keypads Plus series:3KG2
– No-tool Snap-in Front Mounting – Designed for ISO 13849 Safety Rated...
- Keypad buttons: 6, 8, 12, 15
- Five standard keypad form factors available
- Long life cycle: 1M per key
- J1939 and CANopen versions
CAN Bus Keypads series:3KG1
– Keypad buttons: 6, 8, 12, 15, 20 – Five standard keypad...
- Long life cycle: 1M per key
- J1939 and CANopen versions
- Dimmable LED indicators and legends
- Sealed to IP67
7-inch CAN Bus Display series:3D70
– Intuitive touch technology to select objects and swipe through screens –...
5-inch CAN Bus Display series:3D50
– Intuitive touch technology to select objects and swipe through screens –...
CAN Bus Displays series:3D35
This versatile, CAN-based display is ideal for agriculture and construction vehicle applications,...
3.2-inch CAN Bus Display series:3D32
– Can easily display custom graphic icons, text boxes and active gauge...
- Wide temperature range (-50º C to +85ºC) and robust environmental seal (IP67) ideal for off-highway vehicles
10.4-inch CAN Bus Display series:3D2104
– Ideal for gauges, diagnostic menus and other vehicle functions – Capable...
10.1-inch CAN Bus Display series:3D101
– Intuitive touch technology to select objects and swipe through screens –...
- Bright, 1000-nit display is backlit, and provides high contrast text and full color graphics for excellent sunlight readability
Tact Switch series:95CW06
6mm Square, Washable
- Life Rating: Up to 500,000 cycles
- Operating Force (grams): 160, 180, 260, 320, 520
- Termination: SMT, Thru-Hole, Right Angle
Tact Switch series:95C12
12mm Square, Non-Washable
- Life Rating: Up to 500,000 cycles
- Operating Force (g): 100, 160, 260, 320, 520
- cTermination: SMT, Thru-Hole, Right Angle
Tact Switch series:95C06
6mm Square, Non-Washable
- Life Rating: Up to 500,000 cycles
- Operating Force (grams): 100, 160, 260, 320, 520
- Termination: SMT, Thru-Hole, Right Anglev
Tact Switch series:95C05
5mm Square
- Life Rating: 50,000 cycles
- Operating Force (grams): 160
- Termination: SMT
Tact Switch series:95C04
6mm x 3.5mm
- Life Rating: 50,000 cycles
- Operating Force (grams): 160, 320
- Termination: SMT, Thru-Hole
Pushbutton series:7-2000
Audible Click
- Electrical Rating: 10 Amps at 115 Vac
- Circuitry: SPST, SPDT
- Termination: Solder Lug
- Behind Panel Depth-Inches [mm]:0.796 [20,22]
Pushbutton series:46
High Reliability, Bushing and Button Seal
- Electrical Rating: 1/4 Amps at 115 Vac
- Circuitry: SPST, SPDT, DPDT
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.890 [22,61]
Pushbutton series:39-X
Shaft & Panel Seal
- Electrical Rating: Up to 1/2 at 115 Vac
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.215 to .390 [5,461 to 9,90]
Pushbutton series:39-LIMIT
Adjustable Location Settings
- Electrical Rating: 150mA at 115 Vac
- Circuitry: SPST
- Termination: Solder Lug
- Life Rating (cycles): up to 500,000
Pushbutton series:39-5X
1/4"" [6,350 mm] Diameter
- Electrical Rating: 150mA at 28 Vdc
- Circuitry: SPST
- Termination: Thru-hole
- Behind Panel Depth Inches [mm]:0.125 to 0.355 [5,45 to 9, 01]
Pushbutton series:39-2X
Process Sealed
- Electrical Rating: 1/4 Amps at 115 Vac
- Circuitry: SPST
- Termination: Thru-hole
- Life Rating (cycles): 500,000
Pushbutton series:38H
Sub-Miniature, Sealed Per IP67
- Electrical Rating: 1 Amp at 125 Vac
- Circuitry: SPST, SPDT
- Termination: SMT
- Behind Panel Depth-Inches [mm]:0.548 [9,30]
Pushbutton series:38G
Sub-Miniature, Sealed Per IP67
- Electrical Rating: 1 Amp at 125 Vac
- Circuitry: SPST, DPST, SPDT
- Termination: P.C. Mount
- Behind Panel Depth Inches [mm]:0.319 [8,10] to 0.362 [8,30]
Pushbutton series:38F
Sub-Miniature, UL Recognized
- lectrical Rating: 1 Amp at 125 Vac
- Circuitry: SPDT
- Termination: Solder Lug, P.C. Mount
- Behind Panel Depth Inches [mm]:0.155 [3,94]
Pushbutton series:38E
Miniature, UL Recognized, Sealed to IP-68
- Electrical Rating: 1 Amp at 125 Vac
- Circuitry: SPDT, DPDT
- Termination: Solder Lug, P.C. Mount
- Behind Panel Depth Inches [mm]:.663 [16, 85]
Pushbutton series:38D
UL Recognized, Alternate Action
- Electrical Rating: 3 Amps at 250 Vac
- Circuitry: SPDT, DPDT, 3PDT, 4PDT
- Termination: Solder, P. C. Mount, Wire Wrap
- Behind Panel Depth Inches [mm]:0.419 [10,65] to 0.475 [12,06]
Pushbutton series:38C
Miniature, UL Recognized
- Electrical Rating: 3 Amps at 125 Vac
- Circuitry: SPST, DPDT
- Termination: Solder Lug, P.C. Mount, Wire Wrap
- Behind Panel Depth Inches [mm]:SPDT .431 [10, 95], DPDT .390 [9, 93]
Pushbutton series:14
Sealed & Illuminated
- Electrical Rating: 100 mA at 30 VDC
- Circuitry: SPST, DPST
- Termination: SMT
- Life Rating (cycles): 1,000,000
Pushbutton series:10-4000
Momentary, Positive Feel, UL Rated Versions
- Electrical Rating: 3 Amps at 115 Vac
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.688 [16,97]
Pushbutton series:38BT-BH
Miniature Horizontal PC Mount
- Electrical Rating: 1 Amp at 120 Vac or 28 Vdc
- Circuitry: SPST, SPDT
- Termination: Thru-hole
- Life Rating (cycles): 80,000
Keypad series:96
– Conductive Rubber Domes – Backlit Capable
- Array: 3x4, 4x4
- Buttons: 1, 3, 6
Pushbutton series:38BT-BC
Miniature Vertical PC Mount
- Electrical Rating: 1 Amp at 120 Vac or Vdc
- Circuitry: SPST, SPDT
- Termination: Thru-hole
- Life Rating (cycles): 80,000
Pushbutton series:38BM
Miniature Surface Mount
- Electrical Rating: 0.4 VA at 20 Vac or Vdc
- Circuitry: SPST, SPDT
- Termination: SMT
- Life Rating (cycles): 80,000
Keypad series:88
Flange Mounted, Splash Resistant
- Life Rating (Cycles): 3,000,000
- Array: 3x4, 3x5, 4x5
- Buttons: 12, 16, 20
Pushbutton series:32
– Stackable with LED – Electrical Rating: 15mA at 28 Vdc
- Circuitry: SPST, SPDT
- Termination: Thru-hole
- Life Rating (cycles): 100,000
Keypad series:87
Low Profile
- Life Rating (Cycles): 3,000,000
- Array: Single Button, 1x3, 2x3
- Buttons: 1, 3, 6
Pushbutton series:30-46
Snap-in Panel Mount
- Electrical Rating: Up to 1 Amp at 115 Vac
- Circuitry: SPST, SPDT, DPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:1.119 to 1.448 [28, 420 to 6,78]
Keypad series:86
Flange Mounted
- Life Rating (Cycles): 3,000,000
- Array: 3x4, 4x4, 5x4
- Buttons: 12, 16, 20
Keypad series:84S
– Insertable Legend – Screen Print
- Life Rating (Cycles): 3,000,000
- Array: Single Button, 1x4, 3x4, 4x4
- Buttons: 1, 4, 12, 16
Pushbutton series:30-200
Sealed Construction, Threaded Panel Mount
- Electrical Rating: 150mA at 24Vdc
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.48 [12, 192]
Pushbutton series:30-100
Sealed Construction, Snap in Panel Mount
- Electrical Rating: 150mA at 24Vdc
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.540 [13, 716]
Keypad series:84LS
Sealed Construction
- Life Rating (Cycles): 3,000,000
- Array: Single Button, 1x4, 3x4, 4x4
- Buttons: 1, 4, 12, 16
Pushbutton series:30
UL/CSA Recognized Versions
- Electrical Rating: Up to 5 Amps at 115 Vac
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.315 to 0.455 [8, 00 to 11, 56]
Keypad series:84BL
– Screen Print – Sealed Construction – Backlit Capable
- Life Rating (Cycles): 3,000,000
- Array: 3x4, 4x4
- Buttons: 12, 16
Keypad series:84
- Life Rating (Cycles): 3,000,000
- Array: 3x4, 4x4
- Buttons: 12, 16
Pushbutton series:23
– Momentary Contact – Electrical Rating: 1/4 Amps at 115 Vac
- Circuitry: SPST
- Termination: Solder Lug
- Behind Panel Depth Inches [mm]:0.476 [12,09]
- Life Rating (cycles): 100,000
Keypad series:83
0.500"" (12,700 mm) Centers
- Life Rating (Cycles): 3,000,000
- Array: 3x4, 4x4
- Buttons: 12, 16
Keypad series:82
Lightable modules will stack in many configurations
- Life Rating (Cycles): 1,000,000
- Array: Single Button, 1x2, 1x3, 2x3
- Buttons: 1, 2, 3, 6
Precision Joystick series:68B
– Single-Axis with Proportional, Redundant Output – Dynamic IP67 Seal – Available...
Precision Joystick series:67C
– Proportional joystick, pushbutton & optical encoder functions from a single shaft...
Precision Joystick series:67B
– Center shaft pushbutton & momentary z-axis rotation – Minimal depth required...
Precision Joystick series:67A
– Proportional digital output: I2C bus – Long operational life >1M cycles...
NavCoder Multifunction Joystick series:60C
Concentric Shafts for joystick and rotary encoder
- Life Rating (cycles): 1,000,000
- Size - inches [mm]: 1.150 x 1.000 [29,21 x 25,40]
- Size - inches [mm]: 1.150 x 1.000 [29,21 x 25,40]
- Depth Behind Panel - inches [mm]: 0.744 [18,90]
NavCoder Multifunction Joystick series:60AR
– Rugged & Sealed Joystick integrated rotary encoder and pushbutton – Life...
- Size inches [mm]: 1 [25,4] dia
- Depth Behind Panel inches [mm]: 0.932 [23,67]
- Resolution: 20 PPR
NavCoder Multifunction Joystick series:60AD
Customizable joystick force and rotary torque
- Life Rating (cycles): 1M for rotary and pushbutton, 500K for joystick
- Size inches [mm]: 1 [25,4] dia
- Depth Behind Panel inches [mm]: 0.95 [24,13]
- Resolution: 20 PPR
NavCoder Multifunction Joystick series:60A
4 or 8 directions integrated rotary encoder and pushbutton integrated rotary encoder...
- Life Rating (cycles): 1M for rotary and pushbutton 500K for joystick and pushbutton
- Size inches [mm]: 1 [25,4] dia
- Depth Behind Panel inches [mm]: 0.598 [15,18]
- Resolution: 20 PPR
Discrete Joystick series:04JT
Rugged & Sealed (IP67) 4 directions with tactile feedback
- Life Rating (cycles): 250,000
- Size - inches [mm]: 1 [25,4] dia
- Size - inches [mm]: 1 [25,4] dia
- Depth Behind Panel inches [mm]: 0.56 [14,22]
Discrete Joystick series:04J
Rugged & Sealed (IP67) 4 directions plus pushbutton
- Life Rating (cycles): 100,000
- Size - inches [mm]: 1.176 [29,87] dia
- Size - inches [mm]: 1.176 [29,87] dia
- Depth Behind Panel inches [mm]: Behind: 0.443 [11,25] Front: 0.659 [16,73]
Discrete Joystick series:04A
4 Directions
- Life Rating (cycles): 500,000
- Size - inches [mm]: 0.85 [21,59] sq
- Size - inches [mm]: 0.85 [21,59] sq
- Depth Behind Panel inches [mm]: 0.55 [13,97]
Hall-Effect Encoder series:68P
– Ratiometric Analog Output mimics Potentiometer – Sealed against liquids and dust...
- Long operational life: 7M cycles
- Redundant hall effect sensor
Hall-Effect Encoder series:68A
– High Resolution – Quadrature Output with push / pull circuitry –...
Machine Rotary Encoder series:63K
Ball bearing, 4-pin
- Life Rating (cycles): 3,000,000
- Resolution (PPR): 25, 32, 50, 64, 128, 256 (cycles per revolution)
- Body Size inches [mm]: 1.250 [31,75] diameter
- Depth Behind Panel inch [mm]: .500 [12,70]
Machine Rotary Encoder series:61R
Optional index pulse
- Life Rating (cycles): 10,000,000
- Resolution (PPR): 25, 32, 50, 64, 128, 256 (cycles per revolution)
- Body Size inches [mm]: 1.250 [31,75] diameter
- Depth Behind Panel inch [mm]: .500 [12,70]
Machine Rotary Encoder series:61K
Long Operating life
- Life Rating (cycles): 10,000,000
- Resolution (PPR): 25, 32, 50, 64, 128, 256 (cycles per revolution)
- Body Size inches [mm]: 1.250 [31,75] diameter
- Depth Behind Panel inch [mm]: .500 [12,70]
Specialized Rotary Encoder series:62T
Thumbwheel
- Life Rating (cycles): 500,000 to 1,000,000
- Resolution (PPR): 16
- Body Size inches [mm]: .780 x 1.770 [19,81 x 44,95]
- Depth Behind Panel inch [mm]: .750 [19,05]"
Value Rotary Encoder series:62SG
Minimal depth behind panel
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 16, 24, 32
- Body Size inches [mm]: .500 x .580 [12,70 x 14,73]
- Depth Behind Panel inch [mm]: .272 [6,91]"
Premium Haptic Rotary Encoder series:62S
- Minimal depth behind panel
- Life Rating (cycles): 1,000,000 to 3,000,000
- Resolution (PPR): 8, 12, 16, 20, 24, 32
- Body Size inches [mm]: .500 x .540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .289 [7,34]"
Specialized Rotary Encoder series:62R
- Redundant output
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 12, 16, 24, 32
- Body Size inches [mm]: .500 x .540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .933 [23,69]"
Premium Haptic Rotary Encoder series:62N
- Non-turn pushbutton shaft
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 12, 16, 20, 24, 32
- Body Size inches [mm]: .500 x .540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .670 [17,01]"
Specialized Rotary Encoder series:62M
- Magnetic detent, 3M cycles
- Life Rating (cycles): 3,000,000
- Resolution (PPR): 16, 24
- Body Size inches [mm]: 1.100 [27,97] diameter
- Depth Behind Panel inch [mm]: .686 [17,42]"
High Torque Haptic Rotary Encoder series:62HS
- High torque, short behind panel
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 8, 12, 16
- Body Size inches [mm]: .750 x .740 [19,05 x 18,80]
- Depth Behind Panel inch [mm]: .545 [13,84]"
High Torque Haptic Rotary Encoder series:62HR
- High torque, redundant output
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 8, 12, 16
- Body Size inches [mm]: .750 x .740 [19,05 x 18,80]
- Depth Behind Panel inch [mm]: .860 [21,84]"
High Torque Haptic Rotary Encoder series:62HN
- HT, non-turn pushbutton shaft
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 8, 12, 16
- Body Size inches [mm]: .750 x .740 [19,05 x 18,80]
- Depth Behind Panel inch [mm]: .785 [19,93]"
High Torque Haptic Rotary Encoder series:62H
- High torque, concentric shaft
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 8, 12, 16
- Body Size inches [mm]: .750 x .740 [19,05 x 18,80]
- Depth Behind Panel inch [mm]: .878 [22,30]"
Specialized Rotary Encoder series:62F
- LED for knob illumination
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 12, 16, 20, 24, 32
- Body Size inches [mm]: .500 x .540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .657 [16,68]"
Specialized Rotary Encoder series:62C
- Concentric shafts
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 12, 16, 20, 24, 32
- Body Size inches [mm]: .500 x .580 [12,70 x 14,73]
- Depth Behind Panel inch [mm]: .933 [23,69]"
Specialized Rotary Encoder series:62B
- Push and pull to select functions
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 16, 32
- Body Size inches [mm]: .687 [17,45] diameter
- Depth Behind Panel inch [mm]: 1.080 [27,43]"
Value Rotary Encoder series:62AG-VG
- Price competitive solution - AG = 5Vdc, VG = 3.3Vdc
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 16, 20, 24, 32
- Body Size inches [mm]: .500 x .540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .512 [13,00]"
Premium Haptic Rotary Encoder series:62A-D-V
- D = high detent, V = 3.3 Vdc
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 12, 16, 20, 24, 32
- Body Size inches [mm]: .500 x.540 [12,70 x 13,71]
- Depth Behind Panel inch [mm]: .525 [13,33]"
Specialized Rotary Encoder series:61A
- Absolute coding
- Life Rating (cycles): 1,000,000
- Resolution (PPR): 8, 16, 32
- Body Size inches [mm]: .875 [22,22] square
- Depth Behind Panel inch [mm]: .525 [13,33]"
Mechanical Encoder series:51BCD
– Shaft and panel seal – Adjustable stop versions
- Angle of Throw: 30
- Positions: 12
- Body Size inches-Inches [mm]: 0.687 [17,45] diamater
- Depth Behind Panel inches [mm]: 0.537 [13,64]
Mechanical Encoder series:26
– Small size
- Angle of Throw: 22.5, 45
- Positions: 8, 16
- Body Size inches [mm]: 0.500 [12,70] diameter
- Depth Behind Panel Inches [mm]: 0.332 [8,43]
Mechanical Encoder series:25L
– Price competitive to similar designs – Quality construction and contact materials...
- Angle of Throw: 10, 11.25, 15, 18, 22.5, 30, 45
- Positions: 8, 12, 16, 20, 24, 32, 36
- Body Size inches [mm]: 0.865 [21,97] square
- Depth Behind Panel Inches [mm]: 0.343 [8,71]
Mechanical Encoder series:25B
– Multiple code and indexing choices – Reliability tested to listed specifications...
- Angle of Throw: 10, 11.25, 12, 15, 18, 22.5, 30, 45, 60, 90
- Positions: 4, 6, 8, 12, 16, 20, 24, 30, 32, 36
- Multi-deck
- Body Size inches [mm]: 0.865 [21,97] square
Mechanical Encoder series:20
– Smallest with concentric shafts – Angle of Throw: 22.5, 30, 36,...
- Positions: 8, 10, 12, 16
- Body Size inches [mm]: .500 [12,70] square
- Depth Behind Panel inches [mm]: .659 [16 .74]
Touch Encoder series:T1
With highly customizable widgets, the Touch Encoder has the versatility to fit...
Single-Deck Rotary Switch series:77
- Small size, minimal space required behind panel - Available with continuous...
- Poles: up to 2
- Angle of Throw: 36
- Positions: 10
- Rating (max): 200 mA
Single-Deck Rotary Switch series:75
- Small size - Flush, shafted, or knobbed shaft - Poles: up...
- Angle of Throw: 36
- Positions: 10
- Rating (max): 200 mA
- Depth Behind Panel inches [mm]: 0.550 [13,97]
Keylock Rotary Switch series:71J-L
- Economical - Standard or anti-static style - 5-plates, 1-sided key -...
- Poles: up to 6
- Decks: up to 12
- Angle of Throw: 30, 36
- Positions: 10, 12
Multi-Deck Rotary Switch series:71-C
– Two switches in the panel space of a single shaft rotary
- MIL Qualified: MIL-S-3786/39
- Concentric Shaft
- Poles: up to 6
- Decks: up to 12
Multi-Deck Rotary Switch series:71
- Performance and value leader - MIL Qualified: MIL-S-3786/39
- Poles: up to 6
- Decks: up to 12
- Angle of Throw: 30, 36
- Positions: 10, 12
Multi-Deck Rotary Switch series:59
- Smallest diameter rotary switch with this number of positions and current...
- MIL Qualified: MIL-S-3786/36
- Poles: up to 10
- Decks: up to 12
- Angle of Throw: 18
Keylock Rotary Switch series:58
- Minimum space behind panel - Economical - 15,000 Vdc static protection...
- Poles: up to 2
- Angle of Throw: 36, 45, 60, 90
- Positions: 4, 6, 8, 10
- Rating (max): 200 mA
Multi-Deck Rotary Switch series:57
- Smallest diameter rotary switch with this number of positions and current...
- MIL Qualified: MIL-S-3786/36
- Pull-to-turn (isolated positions)
- Poles: up to 8
- Decks: up to 12
Single-Deck Rotary Switch series:56
- Requires minimum distance behind the panel - Adjustable stop types provide...
- Poles: up to 2
- Angle of Throw: 30, 36
- Positions: 10, 12
- Rating (max): 200 mA
Multi-Deck Rotary Switch series:53
- Smallest diameter rotary switch with this number of positions and current...
- Poles: up to 12
- Decks: up to 12
- Angle of Throw: 15
- Positions: 24
Single-Deck Rotary Switch series:51
- Optional complete seal for PC board assembly and cleaning - Small...
- MIL Qualified: MIL-S-3786/35
- Poles: up to 4
- Angle of Throw: 22.5, 30
- Positions: 12, 16
Single-Deck Rotary Switch series:5000
- High quality at a low price - Proven reliability in thousands...
- Pole: 1
- Angle of Throw: 36
- Positions: 10
- Rating (max): 1 Amp
Single-Deck Rotary Switch series:50
- Optional complete seal for PC board assembly and cleaning - Small...
- MIL Qualified: MIL-S-3786/20
- Poles: up to 2
- Angle of Throw: 36, 45, 60, 90
- Positions: 04, 06, 08, 10
Keylock Rotary Switch series:44L
- 8-pin, round key security - Options for flat keys, special keying,...
- Poles: up to 4
- Decks: up to 6
- Angle of Throw: 45
- Positions: 8
Multi-Deck Rotary Switch series:43-54-D-UD-M
– Central shaft designed to operate an add-on potentiometer – Potentiometer mounting...
- MIL Qualified: MIL-S-3786/4
- Add-A-Pot
- Poles: up to 2
- Decks: up to 3
Multi-Deck Rotary Switch series:43-54-A-UA-M
– Two switches in the panel space of a single shaft rotary...
- Poles: up to 2
- Decks: up to 3
- Angle of Throw: 30, 36
- Positions: 10, 12
Multi-Deck Rotary Switch series:42-44
- Rugged construction ensures switch operation for the life of your equipment...
- MIL Qualified: MIL-S-3786/4
- Concentric Shaft
- Poles: up to 6
- Decks: up to 12
Single-Deck Rotary Switch series:24
- Positive Detent Provides Operator Feedback - Stainless Steel or Plastic Shaft...
- Pole: 1
- Angle of Throw: 36
- Positions: 10
- Rating (max): 1 Amp
Single-Deck Rotary Switch series:19
– Rugged Construction – UL recognized
- Pole: 1
- Angle of Throw: 30
- Positions: 12
- Rating (max): 15 Amp
Multi-Deck Rotary Switch SERIES:09
– Proven quality in thousands of applications – Gold-plated contact system
- MIL Qualified: MIL-S-3786/13
- Poles: up to 6
- Decks: up to 12
- Angle of Throw: 30, 45, 60, 90
Multi-Deck Rotary Switch SERIES: 08
– Proven quality in thousands of applications – Gold-plated contact system
- MIL Qualified: MIL-S-3786/13
- Poles: up to 2
- Decks: up to 12
- Angle of Throw: 36– Positions: 10
